GPS ASSET TRACKER
CONSTRUTAG
ConstruTag was designed to adapt to most localization and activity tracking needs, for small equipment or assets in general.
This mini Wi-Fi/GPS tracker allows on the one hand an outdoor geolocation (via GPS/GLONASS), but also indoor geolocation via sniffing of Wi-Fi networks.
Wi-Fi triangulation also reduces the energy consumption of this LORAWAN sensor. The definition of known hotspots also makes it possible to detect if the GPS tracker is currently in a known area.
The device is equipped with a built-in accelerometer, which allows to determine the index of motor activity of the controlled object, to detect shocks and overturns.
Asset tracker has built-in data storage that can be used in the absence of LoRaWAN coverage. In this case, the device continues to work as usual, accumulating data that will be transmitted in strict sequence when the device appears in the network coverage area.
CHARACTERISTIC
PARAMETER | DESCRIPTION |
---|---|
MAIN FUNCTIONS | |
Enclosure dimensions | 54 x 35 x 23 mm excluding fasteners |
Operational temperature range | -40…+85 °С |
Operational humidity range | 0-100% |
Ingress protection rating | IP-65 |
Installation | Using screws, screeds, double-sided tape |
Weight | < 30g |
POWER | |
Operational voltage range | 3.0-3.6В |
Battery | Replaceable Li-SOCL2 Battery ER14335 type |
Battery lifetime | up to three years depending on settings |
GEOLOCATION | |
Geolocation method | Wi-Fi/GNSS |
Geolocation period | customizable |
Wi-Fi frequency range | 2401-2495 MHz |
Wifi sensitivity | –97 dBm |
Wi-Fi transmit power | 19dBm |
Supported global navigation satellite systems | GLONASS/GPS/QZSS |
Number of channels | 99 |
Frequency range | 1575,42-1615,5 MHz |
Sensitivity | -165dBm |
Cold start time | 60s |
Hot start time | 6s |
Embedded RTC sync with GNSS | yes |
COMMUNICATION | |
Communication standard | LoRaWAN 1.0.3 class A |
Radio frequency range | 864-1000 MHz |
Maximum transmit power | 20 dBm |
Sensitivity | -137dBm |
Network activation method | ABP/OTAA |
Supported LoRaWAN regions | RU864/AS923/AU915/EU868/KR920/IN865/US915 |
Adaptive data rate (ADR) | yes |
Data transfer period | from 1 minute to 1 day |
Embedded RTC sync with LoRaWAN network | yes, with adjustable interval |
LoRaWAN packet confirmation | yes, configurable |
LoRaWAN data rate | from DR0 to DR5 |
MOTION ACTIVITY | |
Motion activity calculation method | using the built-in accelerometer |
Motion activity averaging interval | from 15 to 1440 minutes |
Shock detection function | Yes |
Sleep mode if not active | Yes, with adjustable interval |
CONFIGURATION | |
Configuration interface | Bluetooth low energy |
Frequency range | 2402-2480 MHz |
BLE beacon transmission period | 20 seconds |
MAIN FUNCTIONS
Positioning using a Wi-Fi sniffer
Positioning using GPS / GLONASS
Burglary / Tampering detection with Hall sensor
Determination of motor activity and strokes
The body of the monitoring tracker is made of durable sealed plastic, and its design provides protection against dust and short-term immersion in liquid.
You can install the tracker at any place available on the site.
In case of storage of goods in an enclosed area, the asset tracker tracker determines the location by GLONASS
Due to the power supply of the GPS tracker from sources of the ER type (has a capacity of 1650 mAh) and various operating modes, the device works even on long journeys.
Preset options for device operation simplify its configuration:
1. “HOME” mode is active when the device is in range of one of the previously known Wi-Fi access points.
2. “TRACKING” mode is automatically activated when the device leaves the range of known access points.
3. “SEARCH” mode is activated by the downlink command.
By placing a tracker on your movable property, you can track the location of your vans, trucks and other rolling stock. The device allows you to timely detect emergency situations, register collisions, strikes or burglary attempts using a Hall sensor and an accelerometer. Due to the fact that the device is autonomous and does not require recharging, you can install it in the cavity of a car or equipment.
A convenient application for those who often work outside the office, as well as for wireless device settings. After installing the special ConstruTag application, you get access to the device remotely and can use the data from the smartphone screen.
You can install the application through the Google Play Market
USE CASES
The use of LoRaWAN asset tracker allows timely monitoring of servicing services. The use of devices can significantly reduce the misuse of equipment, eliminate downtime, increase the labor discipline of maintenance personnel, and increase safety. The device can provide control of objects without an on-board network (bicycle sipes, electric scooters, gyro scooters, etc.)
CONSTRUTAG allows you to receive information about the location of the transported goods or rented vehicles. Using the tracker, you can monitor the object. Using the tracker, you can record a hit or tamper, as well as determine the ambient temperature of the device.
A wide field of application of the asset tracker device is to optimize the work of companies in the industrial sector by controlling the location of expensive portable equipment and employees. Using the device, it will be possible to control working conditions in the workplace, track the movement of tangible assets, and count hours. In addition, the sensor makes it possible to detect collisions or impacts of cargo.
The device can control movable property in housing and communal services structure (lawn mowers, trimmers, cleaning machines). You can see the detailed history of movement for the period, optimally map the route and control the timing of tasks.
With GPS tracker, you can control the location of expensive portable equipment and employees in the enterprise. With the help of the installed device on the object, you can set the loss in a timely manner, and the installed CONSTRUTAG on the worker’s helmet will allow you to control whether there are any deviations from the work process.
