Taiga Tracker-NB is designed to track the assets both in open areas using a navigation receiver, and indoors, using the iBeacon Bluetooth tag scanner. Energy-efficient data transmission technologies NB-IoT allows you to provide up to 3 years of battery life. In addition to determining the location of the asset. Taiga Tracker-LW allows you to count the activity of movements, detect impacts and the device is made in a shock-resistant sealed enclosure, which ensures operation even in the most severe conditions.
FEATURES
Data transmission Nb-IoT cat. NB2
Outdoor geolocation with embedded GPS/GLONASS receiver
Indoor positioning with embedded iBeacon scanner
Motion activity tracking
Shock detection
Up to 3 years autonomy
Configuring the device and updating the software via Bluetooth from a phone
<b>Enclosure and dimensions</b>
Material;Glass-filled polyamide
Dimensions;125х75х37 mm
Ingress protection rating;IP-65
<b>Operational conditions</b>
Operational voltage;-40…+85 °С (when using batteries that meet climatic requirements and operating conditions)
Humidity;0-100%
<b>Battery</b>
Operational voltage;3.7 V
Battery model;LiMnO2
Quantity battery;3 pcs.
Summary battery capacity;4500 mAh
Battery lifetime;Up to 3 years (depending on settings)
<b>Data transmission</b>
Communication standard;LTE cat. NB2
Radio frequency range;B1, B3, B5, B8, B20, B28
Maximum transmit power;23 dBm
Sensitivity;-129 dBm
<b>GNSS geolocation</b>
Antenna type;Embedded ceramic
Supported GNSS navigation satellite systems;GLONASS/GPS
Number of channels;72
Sensitivity;-167 dBm
Cold start time;40 s
Hot start time;2 s
Embedded RTC sync with GNSS;Yes
<b>Indoor geolocation</b>
Geolocation method;Bluetooth low energy
Scanning period/duration;Configurable
Bluetooth beacon format;iBeacon
Bluetooth beacon filtration;Yes
<b>Additional features</b>
Motion activity tracking;Yes, with configurable interval and sensitivity
Start/stop movement detection;Yes, with configurable timeout
Shock detection;Yes, with configurable sensitivity
Turn detection;Yes, with configurable angle threshold
Temperature measurement;Yes, with configurable inactivity time
<b>Configuration</b>
Configuration interface;With Android mobile application
Device configuration
Taiga IoT mobile application allows you to configure the device and set the necessary operating parameters. The application is supported on devices with the Android 8.0 and later operating system. After installing the Taiga IoT application, you get access to the device and can configure and use data from the smartphone screen.
